Graf EcoBloc Inspect smart Einbauanleitung Seite 19

EcoBloc Inspect smart
Order no. 402500
The points described in these in-
structions must be observed in all
cases. Failure to do so will invali-
date any warranty claim. For any
additional items purchased through
GRAF, you will receive separate in-
stallation instructions
transport packaging.
The components must be checked
for any damage before the system
is transferred to the trench. Dam-
aged blocks must not be used.
You can download any missing in-
structions from www.graf.info or re-
quest them from GRAF directly.
mail@graf.info
www.graf.info
Instructions for installing the
GRAF EcoBloc Inspect smart
CONTENTS
1. GENERAL INFORMATION
1.1 General
1.2 Safety
1.3 Information about operating the system
2. GENERAL PRODUCT INFORMATION
3. TECHNICAL DATA
in the
3.1 Technical data for the GRAF EcoBloc Inspect smart
3.2 Technical data for the GRAF EcoBloc Inspect smart
base plate
4. TRANSPORT AND STORAGE
5. SELECTING THE LOCATION
5.1 Location
5.2 Slope
5.3 Pre-treatment
5.4 Trench dimensions
6. LOAD CATEGORIES
6.1 Installation under surfaces suitable for pedestrian
loading
6.2 Green spaces above the infiltration system
6.3 Installation under surfaces suitable for vehicle
loading
7. INSTALLATION
7.1 Preparing the trench
7.2 Covering with geotextile
7.3 Adding base plates
7.4 Positioning the infiltration ditch elements
7.5 Fitting the inlet
7.6 Connecting the inspection channel
7.7 Backfilling the infiltration system
8. STRUCTURE AS RETENTION VOLUME/RETENTION
TANK
8.1 Structure of retention volume
8.2 Laying geotextile, film and geotextile
8.3 Structure as retention volume / retention tank
9. INSTALLATION UNDER TRAFFIC AREAS UP TO
HGV60
10. USE OF CONSTRUCTION MACHINERY IN THE
INSTALLATION PHASE
11. OTHER APPLICATIONS
