center 03
Connecting the loudspeakers
Important
Before cabling disconnect your
hi-fi system (amplifier, receiver,
power amplifier etc.) from the
mains !
Center Loudspeaker
Connect the speaker outputs of
your multichannel amplifier with
the label Center Speaker with
the
screw
terminals
Re:sound center 03 with correct
polarity.
An invalid polarity results in a
very bad tonal balance up to
missing basses as well as an
unclear
stereo
loudspeaker cables with skinned
ends.
Tighten screw terminals fast
because otherwise they can
cause side noise.
of
the
image.
Use
12
Cable Length & Cross Section
Revox
loudspeakers
consistent electrical phase and
impedance characteristics and
are an uncritical load for the
power
amplifier
loudspeaker cables.
Your specialist dealer offers
loudspeaker cables in diverse
styles and with various cross
sections. He will be glad to
advise you according to your
individual needs.
In order to keep cable loss as
low as possible, we suggest the
following cable cross section
dimensioning scheme:
Cable length
Dimension
bis 5m / 16ft:
1.5 mm
bis 10m / 33ft:
2.5 mm
über 10m / 33ft:
4.0 mm
We advise against using long
cables (more than 20 m / 65
feet) because of inevitable loss.
Re:sound
have
and
the
2
/ AWG15
2
/ AWG13
2
/ AWG11
