Column
Connecting the loudspeakers
Important
Before cabling disconnect your
hi-fi system (amplifier, receiver,
power amplifier etc.) from the
mains !
Connect the loudspeaker outputs A
or B on the back of your amplifier to
the corresponding terminal screws
on the speakers, using loudspeaker
cables with bared ends. Watch the
polarity:
amplifier
-
amplifier
-
Please note:
If one or even more speakers are
connected with the wrong polarity,
there is a significant reduction in the
bass reproduction and the sound
portrait is uneven and diffused.
Ioudspeaker
Ioudspeaker
Cable Length & Cross Section
Revox loudspeakers have consistent
electrical phase and impedance
characteristics and are an uncritical
load for the power amplifier and the
loudspeaker cables.
Your
specialist
loudspeaker cables in diverse styles
and with various cross sections. He
will be glad to advise you according
to your individual needs.
In order to keep cable loss as low as
possible, we suggest the following
cable cross section dimensioning
scheme:
Cable length
up to 5m / 16ft:
up to 10m / 33ft:
over 10m / 33ft:
We advise against using long cables
(more than 20 m / 65 feet) because of
inevitable loss.
10
Re:sound
dealer
offers
Dimension
2
1.5 mm
/ AWG15
2
2.5 mm
/ AWG13
2
4.0 mm
/ AWG11
