Checking gas flow rate on TPSi series MIG/MAG
welding torches with FSC torch connector
Safety

Preparations

WARNING! Work that is carried out incorrectly can cause serious injury and dam-
age. The work described below must only be carried out by Fronius-trained qual-
ified personnel!
(1)
Place the O-ring (2) on the adapter (1)
1
as shown
(2)
Screw the FSC attachment (3) onto the
2
adapter
Start the testbox
3
Turn the welding torch category switch
4
to the - MIG/MAG - position
(3)
63
