Focusing the Dome Camera
NOTE: Ensure this procedure is performed after the dome cover is
installed, so the focus shift caused by the dome bubble's
refraction can be accomodated.
• In the Avigilon Camera Installation Tool, use the camera's
Image and Display settings to focus the camera lens.
a.
b.
Caution — Do not attempt to adjust the focus and zoom on
the camera manually or the camera lens may become
damaged.
For More Information
Additional information about setting up and using the device is
available in the following guides:
• Avigilon Camera Installation Tool User Guide
• Avigilon Control Center Client User Guide
• Avigilon High Definition H.264 Web Interface User Guide
The manuals are available on the Avigilon website:
support-and-downloads.
10
Click the Auto Focus button to focus the lens.
If the desired focus was not achieved, use the focus
near and far buttons to adjust the focus.
