Assembly
Electrical connection
Free cabling
Attention: The cable of the clarios-mini RGB features a wire which is not used (brown). Normally,
the wire is shortened ex works and is not connected.
Connection diagram of the clarios-mini RGB
See respective drawing in the middle of this manual (p. 15).
M12 plug and cabling system
The connection of the clarios-mini versions with M12 connector is quite simple, either with or
without dimming function. Plug the connector of the luminary in a free socket of the M12 cabling
system. The M12 cabling system is coded in a way to avoid wrong wiring or failures. Single-color
lights with M12 plugs are designed for operation on 24 V multiboxes, RGB spotlights are operated
on 12 V multiboxes and with an integrated RGB or RGBW controller. Please plan the components
required for the electrical installation (power supplies, distributors, extensions and plugs for un-
assigned M12 sockets) according to the sales documentation of the M12 cabling system before
placing an order.
Assignment of the M12 connector system monochrome and RGB/ 5-pin ( .41 or .42 )
Pin number Wire color (when
M12 plug plug is removed)
1 brown
2 white
3 blue
4 black
5 green/yellow (gray)
Assignment of the M12 connector system RGBW/WW / 8-pin ( .62 )
Pin number Wire color (when
M12 plug plug is removed)
1 white
2 brown
3 green
4 yellow
5 grey
6 pink
7 blue
8 red
5-pin plug clarios-mini
white / monochromatic
24 V +
24 V +
S-PWM
ground (-)
ground (-)
8 pin connector RGBW/WW
white S-PWM
Mass
green S-PWM
12 V +
Mass
12 V +
blue S-PWM
red S-PWM
5-pin plug
clarios-mini RGB
red S-PWM
green S-PWM
12 V +
blue S-PWM
ground (-)
