Assembly
Electrical connection
The clarios-mini is supplied with DC power and dimmed via a separate PWM signal (pulse width
modulation). A PWM signal (S-PWM) is required for each light color. The PWM input has the following
characteristics:
PWM line connected to ground (-)
PWM line open
PWM line connected to operating voltage (+)
PWM frequency = 0 to 1,000 H
The switching point of the luminary between on and off for the PWM level is not de昀椀ned: Ideally it
should be worked with a switching impulse between ground and open contact or optionally with an
impulse between ground and operating voltage. A PWM signal differing from the operating voltage
is not allowed.
Free cabling
The connection is made according to the assignment tables. The connection must be carried out
according to the required IP classi昀椀cation.
clarios-mini monochromatic with open cable ends (.33, .34, .35...)
Wire color
red
blue
black
Attention: In case the luminary is used without the dimming function, the PWM line (wire for the
PWM signal) must be connected to ground (-). Otherwise the LED remains off.
Connection diagram of the clarios-mini white / with and without dimmer
See respective drawing in the middle of this manual (p. 14).
clarios-mini RGB and RGBW/WW, open wire ends (.33, .34, .35...)
Wire color
white
red
green
blue
black
braun
22
LED on
LED off
LED off
Assignment
12 - 24 V
S-PWM
ground (-)
Assignment
+ 12 Volts
red S-PWM
green S-PWM
blue S-PWM
ground (-)
white S-PWM (only for RGBW/WW)
