Safety
Intended use
The garden and object spot clarios-mini is designed for providing effect lighting for plants and
objects as well as for permanent installation. They are designed for operating in moderate climatic
zones and under water, only V4A variant, (depth 1 m). The luminary is meant for operating with
protective low voltage. In case of detailed lighting planning, please request the light distribution
curves (LDC).
Installation to be carried by an expert
The installation may only be carried out by appropriately trained professionals.
Safety instructions
During installation, the relative safety regulations have to be followed. The spot is operated
with protective low voltage. To avoid danger and failures, prior or any work at the spot or
installation, disconnect the power supply from the mains. The spot can't be opened. Connect the
spot only to power supplies whose output voltage does not exceed 24 V for monochrome or 12V for
RGB. A wrong voltage may destroy the spot and the power supply.
Observe the installation manual of the power supply. Do not overload the power supply! The overall
power consumed by all consumers connected to the power supply should be approx. 10% lower
than the rated power of the power supply being used.
In order to protect the exposed connection cable from rodents it should be protected against mar-
tens (see installation accessories).
High ambient temperatures shorten the life of the LED's. Ensure a good heat dissipation in order to
guarantee a long life of the LED. During operation, do not expose the spot to ambient temperatures
of > 50°C. Do not cover the spot, provide free air circulation.
Do not open the housing of the luminary. The tightness of the clarios-mini is only guaranteed if also
the outer sheath of the connection cable is undamaged and if the connection cable is bonded in a
waterproof way. Otherwise, because of the capillary effect, the penetrating moisture can reach and
destroy the electronics of the spot.
Assembly
Preparation
Unpack all the parts included in the scope of delivery and check them for completeness and in-
tactness. Dispose of the packaging material no longer needed in accordance with applicable reg-
ulations.
If you notice any damage from transport, immediately contact the dealer where you purchased the
luminary.
