Product description
Technical description
The clarios-mini is a compact garden and object spot with built-in 3 W high-performance LED or
4W RGBW/WW LED. The single-colored clarios-mini spotlights can be operated with a voltage of
12 - 24 V DC. The RGBW/WW models with 12 V DC. The housing is completely made of V4A-type
stainless steel and ESG glass. The protection class of IP 68 also allows permanent installation un-
der water. In the "alu black" variant, the housing is made of aluminum and ESD glass, the protection
class is IP 67 and not suitable for permanent use under water.
Thanks to its high brightness the clarios-mini offers an atmospheric illumination for trees, plants
and architecture. It can be continuously rotated by 360° and pivoted by 180° and is available with
different beam angles. The THERMOPROTECT system avoids overheating of the spotlight ensuring
a very long life of the LED.
Technical data
Rated voltage
Power consumption
Connection cable
Protection class of the
spot
Temperature range
Storage Temperature
Thermal protection
Illuminants
Housing
These lights contain a light source with energy ef昀椀ciency class E or F
18
12-24 V DC single color; 12 V DC RGB/W/WW
3 W or 4 W for RGBW/WW
5 m with open cable end, 0.3 m or 5 m with M12 plug
IP 68, up to 1 m water depth / for „alu black" IP 67
- 25 °C – +50 °C
- 40 °C – +80 °C
THERMOPROTECT system
not replaceable, high-performance quality LED with integrated driver
electronics
V4A stainless steel or aluminum coated, hardened glass pane, 4 mm
40 mm
52
mm
47 mm
40 mm
60 mm
