7
1. General information
These instructions contain specific operation and service information about the 0270 Time Code version.
Further information may be obtained from the following manuals:
Revox C270 operation instructions....................... .. ..
Revox C270 schema
Revox 0270 service
Studer TLS 4000 Mkll synchronizer manual ...
Studer C27X - TLS 4000
2. Operating principle
The 0270 TC records the SMPTE
head.
The timecode electronics system has been fully integrated into the C270 chassis and, by use of a
microprocessor, user controls have been kept to a minimum without sacrificing specification.
The system will correctly read and record timecode at 24,25,29 and 30 frame standards. The intemal
microprocessor calculates in real time the offsets required between the audio and timecode record
heads, (whilst recording), and the audio and timecode replay heads (in PLAY mode), and the audio
record and timecode record heads when in sync mode. The system also takes into account the machine
speed.
A "GOOD CODE" LED indicator shows either the quality of timecode being replayed or that timecode is
being supplied to the 0270 from an external source in RECORD and "RECORD READY' mode.
Bymeans of the STUDERTLS4000 Mkll synchronizer master and slave of the types 0270 TC/C274/C278
can be linked to eachother. The TLS 4000 Mkll, equipped with the interface C27)(, can be connected to
the time code outputs as well as to the parallel remote control connections of master and slave. The
master tape drive data are transmitted by the MASTER TALLIES cable and the slave is controlled by the
TLS 4000 Mkll through the PARALLEL REMOTE CABLE.
3. Operation
3.1 Specific elements of the C270 TC version
The outfold pages with the C270 TC front and top view may be used.
time code recording/playback
[21 GOOD CODE LED
[3] SAFE READY LED
SAFE READY Taste
[4]
[5] PARALLEL REMOTE
Time Code output sockete
[7] Time Code input socket
3.2. On Power Up
When the machine is first turned on the microprocessor executes a diagnostic self-check, on completion
of which the "GOOD CODE"
3.3 Playback Mode
Load a centre-track timecode tape and set machine into play, the "GOOD CODE" LED will light, indicating
that the system is reading the tape correctly. Timecode will be available at the output XLR.
collection ...............................
manual
Mkll interface documentation
timecode between
head
socket
and "SAFE/READY"
. order
order
order
order
order
the audio-tracks with an additional
LED's will flash on once.
RAIOX
no. 10.30.1500
no. 10.30.0691
no. 10.30.0920
no. 10.27.1040
no. 10.27.1620
centre-track
