KEEP WARM
This feature allows you to keep your food at an ideal temperature, usually after
cooking is complete or reducing liquids very slowly.
Ideal for serving foods at the perfect temperature.
SIMMERING
This function is ideal for maintaining a simmering temperature, allowing you
to cook food for long periods with no risk of burning.
Ideal for long-cooking recipes (rice, sauces, roasts) with liquid sauces.
BOILING
This function allows you to bring water to the boil and keep it boiling, with
lower energy consumption.
About 2 litres of water (preferably at room temperature) should be placed
in the pan.
In all cases, users are advised to closely monitor the boiling water and
check the amount of water remaining regularly.
If the pots are big and the water quantity is higher than 2 litres, we
recommend using a lid to optimize boiling time.
CHEF CONTROL
The exible zone is divided into three cooking zones
(see the gure) activated at a pre-set power (high,
high
medium or low) depending on the position of the
pot/pan: move the pot/pan over the surface to
continue cooking at di erent temperatures without
medium
having to use the controls.
low
WI FI KEY
How to connect the cooktop to the Wi-Fi network
To connect the cooktop to the user's Wi-Fi network using the mobile App:
turn on the cooktop, press and hold the Wi-Fi button for at least 1 second (as
it's touched, a sound will be heard) and for no longer than 2 seconds. As it's
released, a long sound will be heard. Follow the instructions via the mobile
App. If a second sound before the longer one is heard, the connection to the
user's Wi-Fi network by the router's WPS button procedure has been activated
(see the following paragraph); please read the "WI-FI CONNECTION RESET
PROCEDURE" paragraph if you do not want to follow this procedure and run
the connection to the Wi-Fi network again using the mobile App.
INDICATORS
RESIDUAL HEAT
If "H" appears on the display, this means that the cooking zone is hot. The
indicator lights up even if the zone has not been activated but has been
heated due to the adjacent zones' use or because a hot pot has been placed
on it.
When the cooking zone has cooled down, the "H" disappears.
To connect the cooktop to the user's Wi-Fi network using the router's WPS
button: turn on the cooktop, press the Wi-Fi button (as it's touched, a sound
will be heard) and keep it pressed for 3 seconds until a second sound is heard,
then release the button. As it's released a long sound will be heard. Press the
WPS button on your router within a maximum of two minutes. Follow the
instructions via the mobile App.
PLEASE NOTE: If the user connects the cooktop but later decides not to
use the Wi-Fi function, the connection can be stopped at any time without
following the procedure described below: while the cooktop is on, press the
Wi-Fi button (as it's touched, a sound will be heard) and keep it pressed for
7 seconds until a second sound will be heard, then release the button. As
it's released a long sound will be heard. To connect the cooktop back, press
the Wi-Fi button (as it's touched, a sound will be heard) and keep it pressed
for 3 seconds until a second sound will be heard, then release the button. As
it's released, a long sound will be heard. This procedure allows to restore the
connection, avoiding using the instructions via the mobile App.
REMOTE KEY
How to con rm the commands sent via the mobile app
If the cooktop receives a command from remote (e.g.: a smartphone or a
tablet, through the mobile app) the user is required to con rm it by pressing
the remote control button: turn on the cooktop and keep the remote control
button pressed for at least 1 second (as it's touched a sound will be heard). As
it's released, a long sound will be heard.
How to disconnect the cooktop from the Wi-Fi network
To disconnect the cooktop from the user's Wi-Fi network (e.g. when the router
has to be replaced): turn the cooktop on, press the remote control button (as
it's touched a sound will be heard) and keep it pressed for 7 seconds, until a
second sound will be heard, then release the button. As it's released a long
sound will be heard.
Wi-Fi connection reset procedure
If an incorrect connection procedure has been selected or if any of the
connection procedures described above has to be interrupted before
completed (the cooktop hasn't been connected to the network yet): turn the
cooktop on, press the remote control button (as it's touched, a sound will be
heard) and keep it pressed for 7 seconds, until a second sound will be heard,
then release the button. As it's released a long sound will be heard.
In case the reset procedure hadn't been successfully completed (if the
long sound isn't heard), disconnect the cooktop from the mains for at least
20 seconds and then reconnected it to the mains; then, repeat the reset
procedure from the beginning.
POT INCORRECTLY POSITIONED OR MISSING
This symbol appears if the pot is not suitable for induction cooking, is not
positioned correctly or is not of an appropriate size for the cooking zone
selected. If no pot is detected within 30 seconds of making the selection, the
cooking zone switches o .
