Wall mountinq
1. Hold the mounting bracket onto the installation position with the flat side facing toward the wal
and the curved hole at the ower position.
2. Mark two screw holes according to the holes of the mounting bracket, remove the bracket and
drill the screw holes to a depth of 1.18 in (30 mm) using a 1/4 in (Ø6.Omm) drill bit.
3. nsert the anchor plugs into the holes and tap them with a hammer until their heads are flush
with the wa
4 Screw the mounting bracket to the wal using the provided screws or two 0.14 x 0.98 in
(3.5 x 25 mm) countersunk screws.
5. Attach the a arm to the mounting bracket and tighten it by twisting clockwise.
6. Test the unit by pressing the TEST/HUSHbutton. Ensure the unit sounds in an alarm pattern.
Operating Instructions
Test your alarm by holding the TEST/HIJSHbutton until the unit beeps once and the red LEDflashes
once, then release the test button. The blue backlight will be lit, and the unit will proceed to beep 4
times with the red LEDflashing 4 times. After 5 seconds of si ence, the unit will beep 4 times with
the red LED flashing 4 times again. tis then fol owed by a single beep and the red LEDflashing
once. The LCD display will show" -n, t hen "PAS" and final y "0".
Hushing
When the CO alarm is sounding an alarm after a suspected false alarm, you can press the
TEST/HUSHbutton and the device will beep intermittent y,the blue backl'ght will be off and the
green LED will be lit. The device will resume its normal monitoring status after 4-15 minutes. f the
CO evel is still at a dangerous evel, the alarm wi sound again.
06
The X SENSE's C 003D battery operated carbon monoxide a arm is programmed to sound an alarm
at the fol owing CO concentrations within the time periods listed:
30 ppm over 120 minutes,
50 ppm for 60 90 minutes,
100 ppm for 10-40 minutes,
and 300 ppm for 0-3 minutes.
When CO is detected and the alarm sounds, the CO concentration will be displayed on the LCD and
a blue backlight will be lit. he red LEDwill flash and the alarm WI Issue4 short beeps, repeating
the cycle every 5.8 seconds. After 4 minutes, the device will issue4 short beeps every 1 minute until
the a arm condition disappears.
CO concentration and symptoms
The table below shows the effects of different levels of CO poisoning on the body:
Parts per million (PPM) Effects on adults
IOO Slightheadache,nausea, f atigue (flu like symptoms)
200 Dizziness and headache
Nausea, frontal headache, drowsiness, confusion and
rapid heart rate. Risk to life after over 3 hours of exposure
Severeheadaches, convulsions,vital organ failures. Death
800
possible within 2 3 hours
WARNING:This device is designed to protect individuals from acute effects of carbon
monoxide exposure. It may not ful y safeguard individuals with specific medical conditions. If in
doubt, consult a medical practitioner.
The fol owing table describes the audible a arm patterns and the recommended actions to take.
