the installation method, please note that the upper and lower two parts of
the wall hanging accessories are not the same, please pay attention to the
installation, one is fixed mounting parts, the other is adjustable mounting
parts.
4. Assembling the adjustable mounting parts
Take out the two adjustable mounting parts, screw them onto the fixed
mounting parts, according with below direction. Be aware of the direction
of these mounting parts.
adjustable
mounting parts
5. Mark the wall according to the dimensions given below for the heater
models you purchased, drill the wall and insert the iron wall anchors into
the holes and tighten the screws. Please note the screws must be fixed
firmly.
fixed mounting parts
adjustable screw holes
EN
Item 10046402
A
893 mm
B
130 mm
Item 10046403
A
1163 mm
B
130 mm
23
