Sungrow SG125CX-P2 Schnellinstallationsanleitung Seite 33

Dimenson / Dimensión / ‫ / اﻟ ﺑ ُ ﻌد‬Abmessungen / Wymiar / Dimension / Dimensión: / Dimensioni / Dimensiune /
Dimensão / Afmetingen / Mitat / Mått / Méretek / Dimensões
1020mm
795mm
Mounting / Montaje / ‫ / اﻟﺗرﻛﯾب‬Montage / Montaż / Montage / Montaje / Montaggio / Montare / Instalação /
Montage / Asentaminen / Montering / Rögzítés / Montagem
1
4
6
* If optimizer or rapid shutdown equipment has been chosen for the system, please scan the QR code or
click the link below to learn more about the product and the relevant installation and wiring instructions.
optimizer:
https://support.sungrowpower.com/productDetail?directoryId=1039
360mm
2
M4
1.5N.m
5
16mm
35N.m
N7
5/6O/n
It is necessary to fix the left and right sides of the
inverter with screws. Otherwise, the inverter may be
unstable.
32
898mm
848mm
4-ɸ12
3
φ12
50mm
