GENERAL
Dimensions:
Width;
Height; 108 mm (4"),(incIuding dust
Depth;
Weight;
.3 kg (6.6 lbs.) (including dust cover)
TURNTABLE
Type:
Linear tracking fully automatic
Motor:
DC motor
DC motor (for tonearm drive) x I
Drive system:
Belt drive
33-1/3 rpm and 45 rpm
Speeds:
Wow
and flutter:
0.07% (WRMS)
Rumble:
60 dB (DIN
Turntable:
28 cm (11")
i 7 cm (7") EP Record Adaptor
I.
2. Turntable
Platter
and Mat
3.
Center Spindle
4.
Dust
Cover
5. Tonearm
6.
Tonearm
Rest
7.
Cartridge
8.
Power
Switch
9.
Record
Size Selector
Button
10. Speed Selector (33/45) Button
11. Power
Indicator
12. Tonearm
Forward
Button
13. Tonearm Reverse Button
14, Cue Button
15. Play/Cut Button
16.
Input/Output Plug
FOR A COÜæeiE
PLEASE
'OPERATION
SPECIFICATIONS
330 mm (13")
cover)
350 mm (13-3/4")
(for platter
drive) x I
(DIN 45 507)
NAMES
OVÉ@ATLOOÖ€T
HIS
ANUAL.
TONEARM
Type:
Dynamic balancedlinear tracking arm
Effective length:
147 mm (5-3/4")
Tracking error angle:
±0.20
CARTRIDGE
Type:
Magnetic type
Frequency response:
20 Hz — 20,000 Hz
Output:
3'mV (I kHz, 50 mm/sec.)
20-8B
Channel separation:
Tracking force:
Impedance:
7 x 10-6 cm/dyne
Compliance:
Replacement stylus:
STY-T42
Specifications for this modelaresubject t o change without
prior notice.
OF PARTS
1
2
3
8
910
—2—
UNIT,
11
121314
15
Figure 2—1
16
Figure 2—2
4
5
6
7
