assist with mounting.
6.
Press the child seat firmly against the backrest of the car seat. Apply a
left-right movement to push the seat base towards the backrest to ensure
it is tightly secured against the car seat.
7.
Position the seat in one of the 5 available recline positions (see: Seat tilt
adjustment) and make sure that the base fits tightly to the backrest of
the car seat (Fig. 3).
8.
Place the child in the seat and adjust the headrest (see: Headrest
adjustment).
9.
Pull out the car safety belt.
10.
Thread the shoulder belt through the green shoulder belt guide positioned
at the bottom of the seat's headrest (A, Fig. 7). Thread the hip belt through
the green hip belt guide (B, Fig. 7).
11.
Fasten the safety belt. You will hear a characteristic click.
12.
Make sure the straps are not twisted.
13.
Check that the straps are correctly positioned in the guides and tight, and
that the buckle is not too close to the hip belt guide.
BUCKLING AND UNBUCKLING THE CHILD IN THE SEAT
1.
Loosen the harness by pressing the tension adjustment button and pulling
on the straps (Fig. 8).
2.
Unbuckle the straps by pressing the red button on the buckle (Fig. 9).
3.
Place the child in the seat.
4.
Bring the strap connectors together (A, Fig. 10) and then insert them
into the buckle (B, Fig. 10). You will hear a characteristic click and a green
indicator will appear next to the buckle button. The harness is now fastened
(C, Fig. 10).
5.
Adjust the headrest (see: Headrest adjustment) and tighten the straps.
6.
To do this, pull the tension adjustment strap (10, Fig. A). To loosen the
harness, press the adjustment button and pull on the shoulder straps (Fig. 8).
Note! Make sure that the harness is tightened properly, fits the child's body
snugly, and the straps are not twisted. Check that the hip straps are positioned
low to protect the child's pelvis. The straps should be tight against the child's
body, but not too tight and causing discomfort.
Note! Children under 87 cm in height may use the seat exclusively with a reduction
insert.
‑ 15 ‑
