To Install
Align the battery ribs with the mounting slots and press
the battery pack down until you hear a "click" (Fig. E1).
Fig. E1 parts description see below:
E1-1 Mounting Slot
To Remove
Depress the battery-release button and pull the battery
pack out (Fig. E2).
WARNING:
To avoid serious personal injury, always
remove the bat tery pack and keep hands clear of the
lock-off lever and variable speed trigger when carrying or
transporting the tool.
STARTING/STOPPING THE POWER HEAD
WARNING:
NEVER OPERATE THE POWER HEAD
WITHOUT AN ATTACHMENT. Do not attempt to start the
power head without an attachment.
To start the power head (Fig. F)
1.
Move the lock-off lever forward and then press the
variable-speed trigger. The power head will start.
2.
The rotational speed of the machine is controlled
with the variable-speed trigger. More pressure on the
trigger results in higher speed; less pressure on the
trigger results in lower speed. Adjust the speed to
suit the task at hand.
NOTE:
The motor starts only when the lock-off lever
is moved forward and the variable-speed trigger is
depressed at the same time.
F-1
Lock-off Lever
F-2
To stop the power head
Move the attachment away from the cutting area and
release the variable speed trigger to stop the power head.
WARNING:
Always remove the battery pack from the
power head during work breaks and after finishing work.
Changing Speed Mode (Fig. G)
This machine features three speed modes.
The speed mode will change with every press of the
speed mode button.
The speed indicator will display the active speed mode:
one light for low speed, two lights for medium speed,
three lights for high speed. The low speed mode provides
better control of the machine and longer operating time
per charge.
NOTE:
turned on or during operation.
When the machine is re-started after a break, the speed
mode will return to the previous speed.
E1-2
Rib
G-1
G-2
Variable-speed Trigger
56 VOLT MULTI TOOL POWER HEAD — PHX1600
The speed mode can be set before the machine is
Speed Indicator
G-3
Battery-status
G-4
Indicator
EN
Bluetooth
®
Indicator
Speed Mode
Button
11
