4.
Pull the shaft of the attachment to verify it is
EN
securely locked into the coupler. If not, rotate the
attachment shaft from side to side in the coupler
until it snaps into place.
5.
Tighten the wing knob securely.
WARNING:
Be certain the wing knob is fully
tightened before operating equipment; check it
periodically for tightness during use to avoid serious
personal injury.
REMOVING THE ATTACHMENT FROM THE POWER
HEAD
1.
Stop the motor and remove the battery pack.
2.
Loosen the wing knob.
3.
Press the shaft-release button, with the button
depressed, pull or twist the attachment shift out of
the coupler.
MOUNTING AND ADJUSTING THE FRONT HANDLE
WARNING:
Always remove the battery pack from
the product when you are assembling parts, making
adjustments, cleaning, or when the product is not in use.
1.
Stop the motor and remove the battery pack, if
installed.
2.
Loosen the wing nut and remove the quick-release
lever, clamping block, and wing nut from the front
handle (Fig. C1).
C1-1 Front Handle
C1-2 Quick-release Lever
Safety Barrier Bar
(only for use with
C1-3
brush cutter or
rotocut attachment)
WARNING:
When the machine is used with brush
cutter or rotocut attachment, the safety barrier bar must
also be installed.
3.
Push the front handle onto the shaft between the
threshold ring and the coupler, make sure that the
front handle is positioned upwards and points toward
the top of the rear handle (Fig. C2).
4.
Insert the clamping block into the handle slot
(Fig. C3).
5.
Align the recessed part in the barrier bar with the
protruding part on the front handle, press the barrier
bar onto the front handle (Fig. C4).
C4-1 Recessed Part
10
56 VOLT MULTI TOOL POWER HEAD — PHX1600
6.
7.
safety purpose, the wing nut cannot be loosened during
the adjustment of the front handle operating position.
8.
handle securely attached.
MOUNTING THE SHOULDER STRAP
Depress the strap carabiner to open it and attach it onto
the shoulder-strap loop (Fig. D1).
There are two ways to release the strap. Take it off from
your shoulder directly (Fig. D2) or depress the carabiner
and disconnect the shoulder strap from the shoulder-strap
loop (Fig. D3).
When wearing the strap, no other wearable should
interfere with the release and removal of the strap.
from your shoulder immediately, no matter what way the
strap is in.
You should not use the single-shoulder strap and double-
shoulder strap simultaneously.
C1-4 Wing Nut
OPERATION
C1-5 Clamping Block
to make you careless. Remember that a careless fraction
of a second is sufficient to inflict serious injury.
so could result in objects being thrown into your eyes and
other possible serious injuries.
accessories not recommended by the manufacturer of
this product. The use of attachments or accessories not
recommended can result in serious personal injury.
WITHOUT AN ATTACHMENT.
INSTALLING/REMOVING THE BATTERY PACK
NOTE: Fully charge the battery pack before first use.
C4-2 Protruding Part
Mount the quick-release lever and tighten the wing
nut (Fig. C5).
Pull the quick-release lever up to move/rotate the
front handle to a comfortable operating position
(Fig. C6).
WARNING:
When installing the safety barrier, for
Fold the quick-release lever to secure the front
handle in place (Fig. C7).
WARNING:
Never use the machine without the front
WARNING:
When an emergency occurs, take it off
WARNING:
Do not allow familiarity with this product
WARNING:
Always wear eye protection. Failure to do
WARNING:
Do not use any attachments or
WARNING: NEVER OPERATE THE POWER HEAD
