Box content
-
BelleCouture OverLock
-
Accessory kit
-
Cover
-
Instruction manual
Flat bed extension/Accessory box
Pull the accessory box to the left to open it and remove the accessories.
3. OPERATION
Accessory kit
The following accessories are included with the appliance:
1.
Needles
2.
Large screwdriver
3.
Small screwdriver
4.
Tweezers
5.
Cleaning brush
6.
Lower cutter
7.
Thread unreeling discs (x4)
8.
Lubricating oil container
9.
Adapters (x2)
Cover
Protects the appliance from dust and dirt. After each use, remove the thread guide holder. The spool
pin, with or without thread spool, must be pushed against the machine as far as it will go. If you have
followed the previous steps, you will be able to fit the cover easily.
Connecting the foot control
Insert the foot control plug into the corresponding socket on the machine. Then, plug it into the power supply.
The sewing speed is regulated by pressing the foot control. In addition, this speed can also be adjusted by means
of the regulator at the upper end of the foot control.
NOTE: if the plug does not fit completely into the socket, turn the plug around. If it still won't fit, contact a qualified
electrician to install a suitable socket. Do not modify the plug.
Power switch
When this switch is in the on position, the machine and a light will turn on.
"O" = off
"I" = on
Cover
Slide the cover to the right until it locks into place. Then, pull it down. The individual threading paths are shown
in colour on the side of the machine, as well as the threading method of the overthreading loop. In addition, the
conversion procedure of the converter and the three most common stitch types are shown.
ENGLISH
41
BELLECOUTURE OVERLOCK
