Troubleshooting
Problem Possible Cause
When using the IsoRocker® Incorrect positioning of the device or
on a hard floor it makes a too high an intensity level.
tapping noise.
My legs are aching You may have the intensity on too high
after treatment. a setting and your muscles are being
overworked.
I have placed my feet on TENS is only available through the
the device but am unable to Electrode Pads.
see the TENS symbol on the
control panel
When using the Electrode The level of stimulation you are using
Pads, the stimulation feels may be too high or you may have
uncomfortable. broken skin.
I am unsure of which
therapy mode I am using
when using the Electrode
Pads.
I suddenly can't feel You may have pressed the other
stimulation when using the stimulation mode button by accident.
Electrode Pads.
You may have accidentally paused the
stimulation session by disconnecting
a pad.
When using the Thigh Your muscles may not yet be strong
Pads, my thigh muscles are enough to carry out a full 20 minute
aching before the end of
session.
the treatment.
When using the Thigh Pads,
Therapy has started and has reached
I can't feel the stimulation the rest period.
in my thigh.
For more information including Frequently Asked Questions,
please visit www.revitive.com
26
7377_IFU01_19015432.indd 26-27 7377_IFU01_19015432.indd 26-27
Solution
Adjust the positioning of the device or lower
the intensity level to reduce the device
tapping. Alternatively use a floor mat under
the device to cushion the sound.
Leave adequate time after each treatment
to allow the muscles to recover (just like
after vigorous exercise!). On your next
session start on a lower setting (where you
can feel the mild electrical stimulation and
it is comfortable) and reduce the duration
until your muscles have acclimatised to the
stimulation.
Decrease the stimulation level using the
(–) intensity control on the device or remote
control. You may need to discontinue use
until skin has healed.
Look at the display on the device. If the
Electrode Pads are in EMS mode, you will
see the EMS symbol. If the Electrode Pads
are in TENS mode, you will see the TENS
symbol.
Pressing the opposite stimulation mode
button (i.e. pressing the TENS button when
already in EMS mode or vice versa), will
reset the timer back to 30 minutes. The
intensity will also be reset to zero. The
mode, intensity and time settings will need
to be re-made.
Reconnect the pads to your body or re-
connect the cord and press the (+) to resume
your session.
Turn the device off and end the session
before the end of the 20 minutes. On
your next session start on a lower setting
(where you can feel the mild electrical
stimulation and it is comfortable) and
reduce the duration until your muscles
have acclimatised to the stimulation.
You will need to wait for up to 20 seconds
before the stimulation will start again.
Technical Specifications
Name of product
Model
Frequency (+/- 10%)
Output current
Weight (+/- 0.5kg)
Dimensions
Power consumption
AC adaptor
Power source
Input (adaptor used)
Output
Battery
Battery Life
Applied parts
Parts of Revitive that in normal use come
into physical contact with the user.
Durable Period (Service Life) of Device and
remote control
The Remote Control replicates the controls found on the device
Operating Frequencies
Operating Range Distance
EN
Revitive Medic Knee
5574AQ
EMS: 20Hz – 53Hz
TENS: 80Hz - 130Hz
EMS: Max 15mA
TENS: Max 19mA
1.4 Kg
360mm (Ø) x 76.5mm (D)
5W
CE Approved
100-240V AC ( ), 50/60Hz, 0.18A
5V ( ) DC ,1.0A
Lithium Ion, 1200mAh, 3.7V
500 charge cycles
Small Electrode Body Pads - 5cm x 5cm = 25cm
2
Large Electrode Thigh Pads - 10cm x 12.5cm = 125cm
2
SoftTouch Pads (Foot-Pads) - 253.69cm 2
4 Years
38 KHz
0 to 25m at horizontal
0 to 18m at +/- 30 degree angle
from the horizontal.
