Instructions for use
Step 4: Using the Dual Mode Electrode Pads
Electrode Body and Thigh Pads are for single person use only. Do not share with others.
Full Body Pain Management is achieved with the use of Electrode Body Pads, by selecting from two proven therapies
EMS (Knee Program) and TENS.
1. EMS (Knee Program) Mode
Use the large Revitive Thigh Pads in EMS mode to deliver the unique
Knee Program to strengthen the muscles at the front of your thigh
(quadriceps).
Strengthening your quadriceps muscles may help to support and
stabilise the knee, reduce stress on the knee and relieve knee pain.
Use Thigh Pads on the thigh of your affected leg (knee) once a day for
20 minutes, 5 days per week at an intensity that provides you with
strong but comfortable muscle contractions.
Do not use Revitive more than 6 sessions of 30 minutes (or the
equivalent) per day. This may result in muscle fatigue.
The Body Pads cannot be used at the same time as the foot-pads.
Using the Body Pads will automatically turn the foot-pads off.
Do NOT use the Body Pads on your head, face, neck or chest.
a
Clean and dry the area you will place the Electrode Pads (see next page for positioning instructions).
b
Make sure Revitive is switched off. If the control panel is still illuminated, press the power button and turn
Revitive off.
18
7377_IFU01_19015432.indd 18-19 7377_IFU01_19015432.indd 18-19
2. TENS Mode
Use the smaller Revitive Body
Pads in TENS mode for pain
relief from arthritic/knee-joint
pain. Use for 20-30 minutes per
session as and when required.
Use at an intensity that provides a
strong but comfortable tingling
sensation without causing you
pain.
c
Attach the ends of the Electrode Pads to the Electrode cord.
Press connectors until there is no gap between them.
Leaving a gap may cause discomfort.
d
Plug the other end of the Electrode cord into the opening
on the side of Revitive.
e
Remove the plastic liner from the Electrode Pads, by peeling it off carefully.
Replace the Electrode Pads onto the plastic liner after use.
Large Electrode Thigh Pad placement for muscle strengthening Knee Program -
EMS Mode
f
Gently press one Thigh Pad across your thigh (1), a few centimetres away from
your groin area, with the adhesive side against the skin.
Gently press second Thigh Pad across your thigh (2), a few centimetres from the
1
top of your kneecap, with the adhesive side against the skin.
The Thigh Pads do not need to be lined up exactly with each other. They need to
be in a position that is comfortable and that allows you to see your thigh muscles
contract & relax.
2
EMS mode (Knee Program) should only be used with the large electrode
thigh pads. The small electrode body pads will not be effective in
mode.
EN
EMS
19
