Instructions for use
Cleaning and storing Revitive
a
Ensure Revitive is switched off.
b
Wipe down the foot-pads with a soft damp cloth.
Do not clean with chemicals.
Do not immerse Revitive in water.
c
Store Revitive in a cool, dry and dust-free location and out of direct sunlight.
d Place Electrode Pads onto the plastic liner.
e Store the Electrode Pads in a dry and ventilated location and out of direct sunlight.
You do not have to detach the Electrode Pads from the Electrode cords to store them.
Replacing the Batteries
The remote control requires two AAA 1.5V batteries to operate.
Replacing the Electrode Pads
The Electrode Pads are reusable up to 20-30 applications. If the Electrode Pads start to lose their adhesiveness, rub a few
drops of water into the surface. Replacement Electrode Pads can be obtained via www.revitive.com.
24
7377_IFU01_19015432.indd 24-25 7377_IFU01_19015432.indd 24-25
Troubleshooting
Problem Possible Cause
Revitive is on (lights Not placing both bare feet on the
illuminated on the foot-pads at the same time.
LED display) but
I cannot feel the
electrical stimulation
Your feet may be dry.
through the foot-
pads.
You may be dehydrated.
The intensity level may be on too
low a setting.
Electrode cord is connected to
device.
Revitive may be in auto-pause
If, having tried the solutions
above, you still cannot feel the
stimulation:
No power or lights
AC Adaptor not switched on at the
to Revitive when it is electrical socket or AC Adaptor not
switched on. plugged into device properly.
Flat battery
Revitive is not
REVITIVE IS NOT DESIGNED TO VIBRATE.
vibrating.
The IsoRocker® is not It is the muscles in your legs
"rocking". that cause the "rocking", the
IsoRocker® is a pivot.
The device is too far in front
of you.
EN
Solution
Ensure that your feet are bare and each foot is placed on
each of the foot-pads at the same time. Keep increasing
the intensity up to a maximum of 99 until you feel the
stimulation.
Moisturise the soles of your feet to improve conductivity
and stimulation and try the procedure again. You may
also have to increase the intensity level.
Drink plenty of water before and after using the device.
The device uses your body to create the electrical
circuit. Water is an excellent conductor of electricity
and if your body is less hydrated (below 60%) then the
stimulation may be less, therefore it is important to
always remain well hydrated.
This is a very safe device. Keep increasing the intensity
level towards 99 until you feel the stimulation. You
may find that you have to increase the intensity level
as you get used to the therapy. The aim is not to get to
99 but to find a setting that produces strong muscle
contractions in your calves and is comfortable for you.
Disconnect the Electrode cord - the foot-pads will not
work while the Electrode cord is plugged in.
Ensure that you have drunk plenty of water and that
your feet are well moisturised. Place both feet onto the
foot-pads, then press (+) intensity button to resume
stimulation.
Test the device by placing one hand across both foot-
pads at the same time (The heel end of the foot-pads
is easiest). With your other hand, and starting from
zero, increase the intensity level until you can feel the
stimulation. If you can feel the stimulation through your
hand then the device is working. If on 99 you still cannot
feel the stimulation then please contact your authorised
dealer.
Check electrical socket power is switched on and the AC
Adaptor is plugged into the device correctly. If still not
working – contact your authorised dealer.
Plug device in an electrical socket and charge battery or
run using mains power option.
The IsoRocker® will only rock when increased to
an intensity which causes sufficient calf muscle
contraction. It may be that you cannot comfortably
increase the intensity high enough until you get used to
the sensation. It is important that intensity is adjusted
to a level that is comfortable.
Sit with your knees at a 90 degree angle.
