eta Fenite Wave Bedienungsanleitung Seite 16

EN
II. FEATURES OF THE DEVICE (FIG. 1)
A – curling iron
A1 – ON/OFF switch
A2 – temperature setting button
A3 – light operating and temperature
achieving signalization
A4 – sliding switch - rod height
adjustment
A5 – adjustable rod
III. INSTRUCTIONS FOR USE
Remove all packing material, take out the appliance. Remove all possible adhesion foils,
stick-on labels or paper from the appliance. Put the curling iron in position on a suitable
even surface (control elements up). Check whether the iron is locked in closed position
(using lock A8). Plug the fork of the power supply A10 into el. outlet.
ON/OFF switch
(A1)
Press and hold switch A1 (approx. 2 s) to switch on the appliance. Indicator lamp A3 starts
flashing to indicate heating is on. Press and hold switch A1 (approx. 2 s) again to switch off
the appliance (signal lamp A3 goes off).
Temperature setting button (A2)
Set the required temperature (160 °C, 180 °C, 200 °C, 210 °C) according to hair type using
button A2. Indicator lamp A3 will go on to indicate set temperature. Then the temperature
will be kept automatically.
When you switch ON the appliance and set the required temperature, the signal
light A3 (indicating the relevant temperature) is flashing. As soon as the required
temperature has been reached, the signal light A3 is ON continuously.
Sliding switch - rod height adjustment (A4)
Use switch A4 to adjust the height of central rod A5 (18/22/26/32 mm) and, thus, the curl
(depth) size.
Lock (A8)
Lock the curling iron in closed position by turning the lock A8 towards „
A8 towards „
" to unlock the curling iron.
Automatic switch OFF
Auto power off (60 min.).
Styling the hair
Use the curling iron for dry or damp hair, never for wet hair. Comb the hair before use of
the curling iron (the hair should not be ruffled). Switch on the appliance and allow it to heat
up to the required temperature. Where necessary, you also can adjust the rod height.
A6 – upper heating zone
A7 – lower heating zone
A8 – lock
A9 – turning joint of the power supply
A10 – supply cord
B – case
Note
16
/ 34
". Turn the lock
