Danfoss CCR3 Installationshandbuch Seite 5

Installation Guide
5. Control start menu
6. Control reading menu
Heating Solutions
CCR3 Controller
Start process
After switching the controller detected SD card on
and verified card memory.
If the card is placed correctly, the controller will verify
the present files:
• access
• one set
• all set
If the above-mentioned file is detected, the controller
will ask whether it should be used or aborted.
If no files (new card, used for the first time) there will
be no request.
The next controller will automatically generate a folder
with files:
• folder ACCESS:
allow change of access code to menu (details on
request or www.danfoss.com side)
No. LCD Display Description
1 Danfoss Welcome Menu
OPCCR-3.12 Abbreviation: the type of the CCR3 Controller
2 SD Free Diagnosis: available SD card memory
.....
3 SD Free Available memory In MB
1996 MB e.g.: 2 GB
4 NO No SD card in CCR3
SD CARD! Only when no card in CCR3
5 072254 Series number of CCR3 and number of software.
123456 Code used for services.
6 Thu On Day of the week: Mon, Tue, Wed, Thu, Fri, Sat, Sun.
12:59:32 12:59:32 Real time: hour, minute, second
7 09-10-06 Real date
12:59:32 Real time: hour, minute, second
When the setup is complete, the reading display will
be shown on the screen.
Pressing the "+" key turns the subsequent reading
display on. The "-" key turns the previous reading
display on.
No. LCD Display READING DESCRIPtION
8 Sensor0 Current return temperature measure by sensors.
............ Information: S0 – supply temperature, S1-S16 – return temperature measure in risers.
When info display Sensor .... Open ( no sensor ), when : Sensor ..... Closed ( short cut ).
9 Valve1 Status of control valves, display from V1-V16
....... Information:
0 % ON no control signal for actuators (valve fully open when NO is used) or 100 % OFF (valves is closed).
During the controlling intermediate status is displayed: e.g. 17 %
10 SetT R1 Information about setting return temperature correspondent to current flow temperature, in C degree.
....... Display for R1-R16, e.g.: 45,0 °C
11 Time Current date and time
......... e.g.: 10-04-27
17:45:10
12 Archiver Information about number of data storage in SD card(files)
AC xx e.g.: 38 storage file, InProces
xx = number of stored files; 1 file stored per day
• folder DATA: file with record date folder SETTINGS
with files
- all set: file with settings. Each time the of control
is switched on, setting parameters are archived.
This function provides verification history of all
settings
- arch.set: file with archive of all settings.
Switching the controller on for the 2
above-mentioned record file the request procedure
for setting change or abortion will start.
Display information during the start process
After switching the CCR3 Controller on, the LCD
display automatically presents the start menu.
The table below shows the various information
and change possibilities during the operation of
CCR3 Controller.
Pressing an arrow "▲" result in exit from the reading
displays and enter to the ACCESS CODE menu,
described in chapter 7.
When exit from the menu the first reading display
is shown. A list of readings and possible displayed
options are shown in the table below.
