blades. The use of such non-original
parts can cause personal injury and
irreparable damage to the equip-
ment and will result in immediate
invalidation of the guarantee.
Cleaning the Equipment
• Clean the cutting device and protective
cover of grass and earth after each cut-
ting procedure.
• Always keep the handles clean and
free of grass.
• Clean the equipment with a soft brush
or a damp cloth.
Protect the equipment from
damage! The equipment is to be
neither sprayed with water nor placed
in water. Do not use detergents or sol-
vents. These could cause irreparable
damage to the equipment.
Changing the Reel
The protective cover must be
fully mounted when using the
thread spool. (See Chapter:
"Removing/mounting the protective
cover extension")
1. Switch off the engine.
2. Place the equipment on the ground and
ensure that no fuel leaks and that the
equipment is safely supported.
:
Fig.
3. Press the lock button (16) to lock the
uptake spindle (48).
4. Screw the spool cap (27) clockwise
from the uptake spindle (48).
:
Fig.
5. Open the spool cap (27) by firmly
52
pressing the click lock (52) inwards on
both sides of the spool cap (27), and
remove the spool cap cover.
A slotted screwdriver can be used to
assist in opening the spool cap.
Proceed with caution: do not damage
the spool.
6. Place the new spool (53) in the spool
cap cover (27) and insert the two ends
of the line through the line outlet loop
(54).
7. Place the spool (53) in the spool cap
cover (27) and allow the cover to latch
back into the spool cap (27).
Ensure that the line outlet loops (54)
match the two recesses (55) in the spool
cap otherwise the cover will not close.
:
Fig.
8. Press the lock button (16) to lock the
uptake spindle (48).
9. Unscrew the spool cap (27) anticlock-
wise from the uptake spindle (48).
10. Pull on both ends of the line to release
the lines from the grooves.
11. Trim the thread line to approx. 15 cm
to release strain on the engine when
starting and warming up.
The spare parts which are to be
ordered can be found in the "Spare
parts/accessories" section
Changing blades
Risk of injury! Caution - sharp
edges! Wear gloves.
Changing the 3-tooth blade:
The protective cover must be
shortened when using the
blade. (See Chapter: "Removing/
mounting the protective cover ex-
