Components

Front side
1
2
3
4
5
Back side
12
13
1
Mini-joystick
2
Toggle switch
3 Display
4 LED
5 Rotary knob (left/right side)
6 3D-joystick
7 USB-C port
8 On switch
24
11
9
Push button
10 Operating pen
11 Magnetic holder for the operating pen
12 Laser
13 Latches
14 Tablet camera
15 LED spot
10
9
8
7
6
15
14
13
