Twin Busch Basic-Line TW X-610 Installation, Bedienung Und Wartung Seite 26

rem_x-610_de_037213122308184.docx
C-300-320302-0
200-501
S-040-030204-0
502
S-005-020080-1
503
C-200-320500-0
200-504
B-014-080251-0
505
B-065-006020-0
506
C-200-320400-0
200-507
S-040-006010-0
508
C-200-320200-0
200-509
C-200-320100-0
200-510
CZ-200-320600-0
200-511
B-014-100551-0
512
B-050-100000-0
513
B-060-006020-0
200-514
B-040-102020-1
515
B-010-060201-0
516
B-040-061412-1
517
C-300-320301-0
200-518
B-065-010040-0
519
B-065-014040-0
520
S-000-027310-0
521
C-200-320700-0
200-522
B-001-060001-0
523
B-050-080000-0
524
B-040-083030-1
525
CW-107-020001-0
200-526
A04 S-015-000008-3
A44 B-010-060161-0
A46 S-015-010808-2
200-531 CZ-200-430100-0
200-532 S-000-059262-0
200-535 CZ-200-430200-0
A41 S-011-010808-0
548 B-007-040061-0
600-540 CW-006-060000-0
Druckfehler, Irrtümer und technische Änderungen vorbehalten.
Gear box lower cover
Bearing 30204
Gear box seal φ20*35*8
Gear Belt pulley
Outer hex bolt M8×25
Key washer 6×20
Worm rod
Bearing 6010
Worm gear shaft
Worm gear
Worm gear shaft spacer
Outer hex bolt M10×55
Spring washer Ø10
Pin 6X20
Flat washer Ø10*20*2
Hex socket head bolt M6×20
Flat washer Ø 6*14*1.2
Gear box upper cover
Key washer 10×40
Key washer 14×40
O-seal Ø 27.8*3.1
Oil resistant seal
Self-locking nut M6
Spring washer Ø 8
Flat washer Ø 8*30*3
Complete gear box
T-union 3* Ø 8
Hex socket head bolt M6×16
T-union 1/8-2*Ø8
Rotating valve casing
O-seal 59.9X2.62
Rotating valve mandrel
Straight union 1/8-Ø8
Hex socket head bolt M4X6
Complete Rotating valve
Twin Busch GmbH
26
