EN
5.4
START THE MACHINE
Figure 11.
1.
Push the on/off button.
2.
Push the lock-out button and pull the trigger.
3.
Push the speed button to adjust the speed
according to the grass condition.
5.5
STOP THE MACHINE
Figure 11.
1.
Release the trigger.
2.
Push the on/off button again to turn the machine
off.
5.6
OPERATION TIPS
Figure 12.
Keep clearance between the body and the machine.
Do not operate the machine without guard in place.
Follow these tips when you use the machine:
• Keep the machine connected to the correctly worn
harness.
• Keep a firm hold with two hands on the machine
while you operate the machine.
• Cut tall grass from the top down.
If grass winds around the trimmer head:
• Remove the battery pack.
• Remove the grass.
5.7
CUTTING TIPS
Figure 13.
• Tilt the machine towards the area to be cut. Use the
tip of the cutting line to cut grass.
• Move the machine from right to left to prevent
thrown debris toward the operator.
• Do not cut in dangerous areas.
• Do not force the trimmer head into uncut grass.
• Wire and picket fences cause cutting line wear and
breakage. Stone and brick walls, curbs, and wood
can wear the cutting line quickly.
5.8
ADJUST THE LENGTH OF THE CUTTING
LINE
Figure 14.
WARNING
WARNING
English
While you operate the machine, the cutting line gets
worn and shorter. You can adjust the length of the
cutting line.
1.
Hit the trimmer head against the ground while you
operate the machine.
2.
Line is automatically released and the cut-off
blade cuts the excess length.
5.9
CUT-OFF BLADE
Figure 15.
This trimmer is equipped with a cut-off blade on the
guard. The cut-off blade continuously trims the line
to ensure a consistent and efficient cut diameter.
Advance line whenever you hear the engine running
faster than normal, or when trimming efficiency
diminishes. This will maintain best performance and
keep the line long enough to advance properly.
5.10
ADJUST THE CUTTING DIAMETER
Figure 15.
The machine is set at a 356 mm cutting diameter.
You can adjust to a 406 mm cutting diameter.
Set the cutting diameter to 356 mm for greater
runtime and 406 mmfor a larger cutting area.
1.
Remove the battery pack.
2.
Remove the blade screws from the cut-off blade.
3.
Turn the cut-off blade 180°.
4.
Tighten the blade screws.
6
MAINTENANCE
Read and understand the safety regulations and the
maintenance instructions before you clean, repair or
do the maintenance work on the machine.
Make sure that all nuts, bolts and screws are tight.
Check regularly that the handles are firmly mounted.
Use only the replacement parts and accessories of
the initial manufacturer.
6
NOTE
IMPORTANT
IMPORTANT
IMPORTANT
