USER MANUAL
TECHNICAL DATA
GENERAL
Product number
Product type
No. of channels
Type
Transformer isolated
No. of inputs
Input type
Input connectors
No. of outputs
Output type
Output connectors
THRU outputs per channel
Input attenuation (PAD)
Ground/lift switch
Additional functions
Operating voltage
Power consumption
Housing
Dimensions (H/W/D)
Weight
Ambient temperature (for operation)
Relative air humidity
Included accessories
AUDIO
Max. input level (< 1% THD, 20 Hz)
Max. input level (< 1% THD, 1 kHz)
Max. output level (< 1% THD, 1 kHz)
Frequency response (±1 dB, relative 1 kHz)
Input impedance (1 kHz, setting: 0 dB PAD)
Output impedance (1 kHz, setting: 0 dB PAD)
THD+N (30 Hz, +4 dBu, unity, unweighted)
THD+N (1 kHz, +4 dBu, unity, unweighted)
IMD (SMPTE) (60 Hz/7 kHz, 4:1, +4 dBu)
SNR (+4 dBu, 22 kHz BW, unity, unweighted)
Transformer ratio
All measurements were performed with a generator with an output impedance of 600 Ω and 1 kΩ balanced load.
EN
PINN
DI box
2
Active
Yes
2
Unbalanced
6.3 mm jack
2
Balanced
XLR
1
0 dB/30 dB
Yes
Additional mono output
2× P48 V, 9–24 V external power supply unit
0.5 W
Aluminium continuous casting
140 × 50 × 128 mm
0.72 kg
- 20°C ... 70°C
< 80% (non-condensing)
Rubber feet, inscription label
+11 dBu
+11 dBu
+5.5 dBu
20 Hz–20 kHz
500 kΩ
110 Ω
< 0.0028%
< 0.0013%
< 0.0017%
108 dB
1:3
