Taurus Hack Squat IFP Montage- Und Bedienungsanleitung Seite 27

7.2 Teileliste
Übergeordnet
Teilenr. Hersteller-Identifi kationsnr.
1 IFP161701ASSY
2 IFP161702ASSY
3 IFP161703ASSY
4 IFP16170400
5 IFP16170500
6 IFP161706ASSY
7 IFP16170700
8 IFP161708ASSY
9 IFP16170900
10 IFP161710ASSY
11 IFP16172000
12 IFP16172100
13 GB70M10*115*115DHS18
14 GB5780M10*100DHS20
15 GB5780M10*75DHS20
16 GB5781M12*30DHS20NL
17 GB5781M10*30DHS20
18 CNLM10*60DHS20
19 GB9510DHS2
20 GB9512DHS2
21 GB9310DHS12
22 GB9312DHS12
23 NM10DHS2
24 NBS6DHS
25 NBS8DHS
26 YHY
Bezeichnung (ENG)
Middle Base Frame ASSY
Rear Base Frame ASSY
Front Base Frame ASSY
Rear Upright
Foot Plate
Top Tube ASSY
Linear Shaft
Carriage ASSY
Limiting Shaft
Weight Plate Storage ASSY
Seat Pad
Back Pad
Socket Head Cap Screw M10*115
Hex Head Bolt M10*100
Hex Head Bolt M10*75
Hex Head Bolt M12*30
Hex Head Bolt M10*30
Flat Head Cap Screw M10*60
Flat Washer Φ11*Φ20*2
Flat Washer Φ13*Φ24*2.5
Spring Washer Φ10
Spring Washer Φ12
Nylon Lock Nut M10
Hex Key S=6
Hex Key S=8
Lube
Anz.
1
1
1
1
1
1
2
1
1
4
1
2
2
10
4
4
8
4
42
4
4
4
18
1
1
1
27
