Intended use
The dehumidifier is only intended for dehumidifying privately used rooms (e.g. for living
rooms, bedrooms, storage rooms or basements). The user must comply with the specified op-
erating parameters of these instructions.
The machine may only be used in accordance with its intended purpose. Any other use beyond
this is not in accordance with the intended use. The user/operator and not the manufacturer is
liable for any damage or injury of any kind resulting from such use.
Operating notes
The device is designed for a temperature range between 5 and 35°C. Below 5°C, the humidity
tends to be very low, so you do not need to use a dehumidifier. Above 35°C, the overheating
protection may automatically switch off the device. The device is not approved for operation
outside the temperature range.
In order for the dehumidifier to dehumidify optimally, it warms the air. Therefore, the room
temperature may rise by 1-2 degrees. This is quite normal and increases the efficiency of the
device.
Allow the unit to stand in its final, upright position for at least 24 hours before
starting it for the first time.
Always operate the device in an upright position only and do not tilt it during
operation.
Technical data
Product name:
Voltage:
Rated power:
Current consumption:
Dehumidification capacity:
Max. Rated power:
Max current consumption:
Max dehumidification capacity:
Max head pump:
Weight:
Permissible operating temperature:
Coolant / Quantity:
Dimensions:
Max. suction/pressure side
Working pressure:
Max. permissible pressure on the
High/low pressure side:
Max. allowable pressure heat exchanger: 3.2MPa
EN-7
Comedes ITR 90
AC220~240V/50 Hz
1080W (27°C 60% humidity)
4.8 A (27°C 60% humidity)
50 l/ day (27°C 60% humidity)
1260W (30°C 80% humidity)
5.6 A (30°C 80% humidity)
90 l/ day (30°C 80% humidity)
5,0 m
55 kg
5-35°C
R290/230g
584x575x1010mm
0.7MPa/3.2MPa
3.2MPa
www.comedes.com
