Tools for Assembly

Step Ladder
#3 Phillips
Screwdriver
(8 ft.)
Rim Assembly
2.75 in. 2.5 in.
(7 cm) (6.35 cm)
Adjust Tension
1. Make adjustments as shown.
2. Tightening the nut which preloads the spring
increases the rim's resistance to movement - the
more the preload, the more force will be required
to move the rim downward.
Level
2.80 in.
(7.1 cm)
4.0 in.
(10.2 cm)
3.0 in.
(7.6 cm)
Socket Wrench Socket Wrench
9/16" & 3/4" Extension
3.36 in.
(8.53 cm)
1.50 in.
(3.8 cm)
2
Pro-Image® Rim Owner's Manual
Wrench
9/16" & 3/4"
3/4"
