10. Manual adjustment of end points
Reset the original connection in accordance with the connection diagrams [ 29 to 31 ] on pages 59 / 60, if
you have carried out the setting with the universal setting cable.
In the event that a malfunction occurs during the setting process, e.g. the tubular motor only runs for a sin-
i
gle rotation even when you press and hold the set button, the adapter (10) may have slipped off the drive
head (12).
◆ Check and, if necessary, correct the positioning of the adapter (10), see page 66.
10.1 Test run / modifying the end points
Test run
1.
Subsequently check the direction of travel, if the
RolloTube S-line DuoFern is being operated using a
switch or button.
Switch the lines for the rotation direction if the
direction of travel is incorrect, see connection
diagram [ 30 / 31 ] on page 59 / 60 .
2.
Check the settings and allow the roller shutter to
run in both directions, until the end points switch
off the motor.
64
ATTENTION!
The tubular motors are designed for transient
operation (approx. 4 min.).
If this period is exceeded, or if the equipment is
switched over frequently, then the motor may heat
up and the thermal protection system will switch
it off.
◆ In this case, allow the motor to cool down for 20
minutes.
Modifying the end points
Move the roller shutter back to the centre position
and begin the process again.
