10. Manual adjustment of end points
1.
First, switch on the mains power or continuous
phase at the universal setting cable.
2.
Move the roller shutters in the desired
direction.
Recommendation
First in upright position.
ATTENTION
A combination of the endpoint adjustment with
a DuoFern radio remote control can cause mal-
functions.
3.
In addition
press the set button on the tubular motor.
4.
Release the button again as soon as the desired
end point is reached.
5.
You can correct the end point in small steps by
briefly pressing the button.
6.
Switch off the specified direction of travel after
successfully setting the end points.
Move the motor briefly in the opposite direction to
save the end point.
7.
Next, switch off the continuous phase at the uni-
versal setting cable.
With the set button on the
tubular motor
ON
Set the Venetian blind switch
to the neutral position and
release the set button.
With the universal
setting cable
OR
The LED on
ON/
button 3 must
SET
light up
continously.
Direction of
I
travel 1
or
Direction of
II
travel 2
press/tap twice briefly
III
and press and hold
the third time.
III
III
I
Set the rocker switch
to the centre position.
II
ON/
SET
EN
