Part number
Type approval
Rated voltage
Operating voltage
Total current
18
consumption
Light function
Interference suppression
class CISPR 25
Power consumption
Dome
Operating position
Protective rating
Temperature range
Inverse polarity
protection
Housing
Technical Data
013 878-001
013 878-011
SAE - J845 Class 2
ECE - R65 TA1
ECE - R10
12 V / 24 V
10-32 V
≤ 0,55 A (Rotating)
≤ 2,1 A (double fl ash)
Flashing and rotating
CISPR 25 Class 3
ca. 9-30 W
PC
Upright
IPX 9K, IP 67
-40 ºC
+60 ºC
yes
PC + ABS black
Program mode description
No.
Flash patterns
1
Double flash
2
Rotating
About the pattern switch , the first pattern is double
flash , the second flash is rotating (Clockwise ) . Use
the yellow wire to touch the red wire then the pattern
will change from double flash to rotating function .
• Black cable = ground (-)
• White cable = plus (+)
• Yellow cable = pattern switch
The product is preset to double flash mode , to change
from double flash mode to rotating . Please touch the
yellow cable = trigger to the red cable = Plus (+).
Operation of the light with alternating voltage is not
permitted!
Calculate the fuse according to the capacity of the
consumer and the cable cross-section required for
this!
2Hz
2Hz
