CHILD SAFETY SEAT REMOVAL
1.
Release the safety belt and remove the hip belt from the hip belt guide and the
shoulder belt from the shoulder belt guide.
2.
To release ISOFIX arms, press and hold the ISOFIX adjustment button on both sides,
and then pull out ISOFIX arms and store them. The indicator on the ISOFIX button
will change to red.
BACKREST REMOVAL AND INSTALLATION
The backrest can be removed. To do it:
1.
Push the backrest to make it horizontal.
2.
Disconnect the backrest catches (11, Figure C) and separate the backrest from
the base.
3.
To reinstall the backrest, place the catches in the relevant base openings and then
raise the backrest to the vertical position.
UPHOLSTERY REMOVAL AND INSTALLATION
1.
Remove the upholstery by sliding elastic holders from the headrest edges (Figure 12).
2.
Remove the upholstery from the hooks in the upper part of the child safety seat
(Figure 13).
3.
Remove the elastic bands from the hooks in the lower part of the child safety seat
(Figure 14) and them remove the upholstery.
To reinstall the upholstery, perform the above steps in the reverse order.
CLEANING AND MAINTENANCE
•
To remove minor stains, use a moist sponge and mild detergent.
•
The upholstery can be washed at 30°C. To do it, remove the upholstery from the
child safety seat completely (see Upholstery removal).
•
Do not tumble-dry. Do not expose the upholstery to sunshine to dry. Plastic parts
can be cleaned with a moist cloth and mild detergent.
•
Please note! Do not use strong detergents or bleaches.
The photos are for illustrative purposes only, the actual appearance of the products may
EN
differ from those shown in the photos.
