EuroLite LED IP Atmo Bar 10 Bedienungsanleitung Seite 36

17
Dimmer CW 9
18
Dimmer WW 9
19
Dimmer CW 10
20
Dimmer WW 10
21
Dimmer R 1
22
Dimmer G 1
23
Dimmer B 1
24
Dimmer R 2
25
Dimmer G 2
26
Dimmer B 2
K
48
Dimmer R 10
49
Dimmer G 10
50
Dimmer B 10
59-Channel-Mode
Channel
1
Master Dimmer
CW WW R G B
2
Strobe
3
Macros
4
Speed
5
000 – 255 Increasing brightness 0-100%
000 – 255 Increasing brightness 0-100%
000 – 255 Increasing brightness 0-100%
000 – 255 Increasing brightness 0-100%
000 – 255 Increasing brightness 0-100%
000 – 255 Increasing brightness 0-100%
000 – 255 Increasing brightness 0-100%
000 – 255 Increasing brightness 0-100%
000 – 255 Increasing brightness 0-100%
000 – 255 Increasing brightness 0-100%
K
000 – 255 Increasing brightness 0-100%
000 – 255 Increasing brightness 0-100%
000 – 255 Increasing brightness 0-100%
Value
000 – 255 Total brightness 0-100%
000 – 004 No function
005 – 064 Strobe effect slow > fast
065 – 127 Random strobe effekt slow > fast
128 – 191 Pulsating strobe effekt slow > fast
192 – 255 Random strobe effekt slow > fast
000 – 000 No function
Macro 1
001 – 025
Macro 2
026 – 050
Macro 3
051 – 075
Macro 4
076 – 100
101 – 125 Macro 5
Macro 6
126 – 150
Macro 7
151 – 175
Macro 8
176 – 200
201 – 225 Macro 9
226 – 255 Macro 10
000 – 255 Increasing speed of Macros under channel 3
000 – 000 No function
K
Function
36/40 00147939.DOCX, Version 1.0
