14-Channel-Mode
Channel
1
Master Dimmer
CW WW R G B
2
Strobe
3
Dimmer CW
4
Dimmer WW
5
Macros
CW / WW
6
Speed
7
Dimmer R
8
Dimmer G
9
Dimmer B
10
Macros
R / G / B
11
Speed
12
Background color Red
13
Background color
Green
14
Background color
Blue
20-Channel-Mode (COB-LEDs)
Value
000 – 255 Total brightness 0-100%
000 – 004 No function
005 – 063 Strobe effect slow > fast
064 – 150 Random strobe effekt slow > fast
151 – 255 Lightning strobe effekt slow > fast
000 – 255 Increasing brightness 0-100%
000 – 255 Increasing brightness 0-100%
No function
000 – 000
Macro 1
001 – 025
Macro 2
026 – 050
Macro 3
051 – 075
Macro 4
076 – 100
101 – 125 Macro 5
Macro 6
126 – 150
Macro 7
151 – 175
Macro 8
176 – 200
201 – 225 Macro 9
226 – 255 Macro 10
000 – 255 Increasing speed of Macros under channel 3
000 – 255 Increasing brightness 0-100%
000 – 255 Increasing brightness 0-100%
000 – 255 Increasing brightness 0-100%
000 – 000 No function
Macro 1
001 – 025
Macro 2
026 – 050
Macro 3
051 – 075
Macro 4
076 – 100
101 – 125 Macro 5
Macro 6
126 – 150
Macro 7
151 – 175
Macro 8
176 – 200
201 – 225 Macro 9
226 – 255 Macro 10
000 – 255 Increasing speed of Macros under channel 10
000 – 255 Increasing brightness 0-100%
000 – 255 Increasing brightness 0-100%
000 – 255 Increasing brightness 0-100%
34/40
Function
The desired RGB macro is
played back with the
selected main color(s) and
background color(s)
