OPERATION
After connecting the device to the mains it is ready for operation. The display indicates the last operating
mode. The operating modes can be selected by means of the display and the control buttons. All settings
remain stored even if the device is disconnected from the mains. The device can be operated in stand-alone
mode via the control board or in DMX-controlled mode via any commercial DMX controller.
Stand-alone mode
In stand-alone mode, the device can be used without controller. Disconnect the device from the controller
and call up the menu you want to use. Please refer to the instructions under Menu structure.
The main menu is accessed by pressing ENTER. Browse through the menu by pressing UP or DOWN.
Press ENTER in order to select the desired menu. You can change the selection by pressing UP or DOWN.
Press ENTER in order to confirm. You can leave every mode by pressing MENU. The functions provided are
described in the following sections.
Menu structure
Main menu
DMX Address
Control Mode
Auto Mode
OPERATE
Auto Speed
MODE
Master/Slave
Static Control
CHANNELS
Blackout *
Hold *
RDM
Display
Reverse
SETTINGS
Dimmer
Curves
Backlight
Screen Time
Current adj
Temp
Sub menu
DMX ADDR 001 – 512
DMX / Art-Net
Off
Auto01 ~ Auto 10
0 - 100
10CH
14CH
20CH
50CH
59CH
ON
OFF
ON
OFF
ON
OFF
ON
OFF
Linear
S_Curve
Log
Exp
ON
OFF
10 ~ 20 S
10°C ~ 85°C
30/40
Function
DMX address setting
Select control protocol
Automatic operation off
Auto programs
Speed of the auto programs
Master setting (Auto)
Slave setting (DMX Address: 001)
Manual settings See Table 1
10-channel DMX mode
14-channel DMX mode
20-channel DMX mode
50-channel DMX mode
59-channel DMX mode
All LEDs off
All LEDs stay on
Last DMX value saved
Last DMX value not saved
RDM-Function on
RDM-Function off
Display reverse 180 degrees
No display reverse
Dimmer curve: Linear
Dimmer curve: S-type
Dimmer curve: Logarythmic
Dimmer curve: Exponential
Screen saver on after x seconds
Screen saver off
Screen saver setting
Service setting only
Service setting only
