3. Before starting up
Remove all packaging material and transport
locks from the unit. Check that the package con-
tents are complete and undamaged.
3.1 Setting up the unit
For safe and fault-free operation of the unit, the
installation site must meet the following requirements:
The floor must be firm, flat and horizontal.
Before use, leave the unit in an upright position
for 2 hours.
Minimum distances of 50 cm to the side and
50 cm to the rear must be maintained from the
enclosure.
Do not place the unit in a hot, wet or very humid
environment or near combustible material.
The power socket must be easily accessible so
that the mains plug can be easily disconnected
if necessary.
3.2 Mounting the hot air outlet hose
Pull the hot air outlet hose
the hose connector (window)
connector (air conditioner)
of the hot air outlet hose
Push the hose connector (air conditioner)
into the rail provided on the rear air outlet 9 .
3.3 Installation of the window seal
Note: Illustrations to help you can be found on the
fold-out page (see Fig. 1-7).
Before starting the installation, first clean the win-
dow and window frame with soap or detergent.
Make sure that the entire surface is free of dust
and grease before attaching the Velcro tape to
the window and window frame (see Fig. 1).
Measure the surfaces and cut the Velcro tape
to the required dimensions (see fig. 2). Then
16
apply the Velcro tape
frame and to the window (see fig. 3).
apart and screw
14
and the hose
15
each to one end
13
.
14
13
around the window
16
Note: Do not stick the Velcro tape
surface.
Attach the window fabric
(see fig. 4).
16
Open the zip of the window fabric
approx. 50 cm (see fig. 5).
Insert the hot air outlet hose
tioner into the opening. Then close the zip fas-
tener so that it closes with the hot air outlet hose
and holds the hot air outlet hose
14
opening (see fig. 6).
4. Start-up
The product has 3 different operating modes: cool-
ing mode, dehumidification mode and ventilation
mode.
Connect the unit to a grounded, fused, freely
accessible wall socket. A beep sounds.
4.1 Select mode
After switching on, press the MODE button
to switch between cooling → dehumidification → fan
mode.
4.1.1 Cooling mode
Press the POWER button
unit on.
Press the MODE button
the "COOL" indicator lamp lights up. This lights
up permanently during operation.
The display 2 now shows the preset / last set
temperature.
You can now set the desired temperature using
the plus button
(temperature range: 16 °C - 31 °C).
Use the temperature unit
change the temperature unit from degrees Celsi-
us to degrees Fahrenheit.
to the glass
16
to the Velcro tape
17
17
of the air condi-
14
in the
14
to switch the
18
repeatedly until
20
and minus button
22
button to
26
GB/IE/NI/CY/MT
