Safety
2.5 Safety Marking
PROHIBITION SIGN
Symbol Meaning
It is not allowed to be under hanging loads. Danger to life!
The device may not be lifted, if the gripping good hangs diagonally.
No manholes may be lifted, if the height of the cylindrical part of the
cover opening is larger than 150 mm.
WARNING SIGN
Symbol Meaning
Danger of squeezing the hands.
REGULATORY SIGN
Symbol Meaning
Inner diameter and tolerance of the manholes.
Position of shifting gate for cones and manholes.
Each operator must have read and understood the operating
instructions
Order-No.: Size:
2904.0210 30 mm
2904.0209 50 mm
2904.0204 80 mm
2904.0333 45x112 mm
2904.0359 45x112 mm
Order-No.: Size:
2904.0221 30 mm
2904.0220 50 mm
2904.0107 80 mm
Order-No.: Size:
2904.0332 40x85 mm
2904.0671 90 x 60 mm
(lift side)
29040672 90 x 60 mm
(right side)
2904.0665 30 mm
2904.0666 50 mm
