Operating Concept
4 .3

"Main Menu" Display

4
3
2
Fig . 6: "Main menu" display (example)
Pos. Name Description
1 Application Shows all available
management applications .
2 Settings Accesses the system settings
of the balance .
3 Leveling Opens the leveling function
of the balance .
4 Calibrate Opens the menu for
balance calibrating the balance .
12 Entris II Advanced Line Operating Instructions
®
1
4 .4

Input Screens

4
3
Fig . 7: Alphanumeric keypad and numerical keypad (example)
Pos. Name Description
1 Input field
2 Input field Indicates which values can
with input be entered in the entry field,
assistance e .g . only numbers .
3 Numeric
keypad
4 Alphanumeric
keypad
1
2
