B) Tripping test when testing RCDs, and when determining offset for
R :
LO
Press the triggering key
Figure 1: Measurement (A) / Tripping Test (B)
3. Press the save/send key
order to save measurement results or send them using the push-print
function.

The indicator LED blinks green three times in order to confirm that
saving has been successful.
Note
The measured values are stored in the last selected mem-
ory location. This location can only be selected at the test
instrument (see operating instructions for the test/mea-
suring instrument).
Figure 2: Save
5.2 MEASURING POINT ILLUMINATION
The probe is equipped with measuring point illumination in order to light up
poorly illuminated measuring points.

Proceed as follows:
1. Press the measuring point illumination key.

Measuring point illumination is switched on.
2. Press the measuring point illumination key once again.

Measuring point illumination is switched off.
Figure 3: Switching Measuring Point Illumination On and Off
I-SK4-PROFITEST PRIME / I-SK12-PROFITEST PRIME
.
B
A
after measurement has been completed in
3 ×
2
1
2
1
4
3
6 STORAGE AND TRANSPORT
ATTENTION
Improper Storage
Damage to the product.

Store the product in a protected location and only within the limits of
the permissible ambient conditions (
ATTENTION
Improper Transport
Damage to the product.

Transport the product only within the limits of the permissible ambient

conditions ( "Technical Data"
protected.
7 MAINTENANCE
7.1 CLEANING
DANGER
Life endangering due to electric shock!
The product is powered by electrical current and there's al-
ways a risk of electric shock. This can be fatal or cause serious
injuries.
 The product must be voltage-free before beginning, as
well as during cleaning. Disconnect the product from the
test/measuring instrument to this end.

Never immerse the product in water or other liquids.

Never touch the product with wet hands.
ATTENTION
Unsuitable Cleaning Agents
Unsuitable cleaning agents such as aggressive or abrasive cleansers result
in damage to the product.

Use a dry cloth for cleaning.

Avoid the use of cleansers, abrasives or solvents.
7.2 TEST TIP REPLACEMENT
The test tip is screwed in and can be replaced. A set of 5 test tips is available
for use as replacement parts (article number Z506Y).
Test tip replacement is described in the product documentation for the set.
 
"Technical Data" 2).

2) and ensure that it's adequately
