close. Tighten the screw on the
underneath of the housing.
Mounting SNG 850-...
7 Clip the line rectifier onto the top
hat rail.
Mounting VIB 150-...
Strip back cable to appr. 80 mm.
8 Recommended mounting height
appr. 1.60 m to display height/
viewing height.
9 Open the device by pushing in
the locking lever and taking off the
front side.
10 When mounting directly on the
wall, fasten the base plate using
4 screws, paying attention that
the plate is the right way up (top
marking).
11 When mounting on a switch box,
use the screw openings in the centre
of the device, paying attention that
the plate is the right way up (top
marking).
12 Install in accordance with the
wiring diagram. The cores of the
installation cable must be stored
inside the free installation space in
the base plate.
13 With Plug+Play programming
do not close the housing until pro-
gramming is under way. Hook the
housing into the base plate from
above and close by exerting a slight
pressure.
Dismantling VIB 150-...
14 To remove the housing, press
the lock upwards. The circuit board
remains in the housing superstruc-
ture.
Lettering
15 Open the nameplate from the
outside, for example using a flat
bladed screwdriver, and carefully
remove the inscription insert. To
insert the nameplate, lock into place
by exerting light pressure.
Installation
16 Connect in accordance with the
relevant circuit diagram.
17 Circuit diagram for
SET CVB 850­... extended with one
Vario door station with BCM 653­...
Note
a) The camera branch and monitor
branch must be laid separately and
must not be located in the same
cable. This can result in disturbance
to the picture composition.
Range
The In-Home bus must be installed
on one pair of cores when using
J-Y(St)Y, and when using a YR
conductor, on two YR cores posi-
tioned side by side. Using J-Y(St)Y
conductors reduces the likelihood of
interference.
SNG 850-... to door station max.
50 m,
SNG 850-... to the most remote
indoor device max. 50 m, with
0.8 mm core diameter.
With a core diameter of 0.6 mm, the
range is halved.
Terminal assignment CV 850-...
TaK, TbK In-Home bus camera
branch
Tö, Tö Relay contact door
release
Terminal assignment VIB 150-...
TaM , TbM In-Home bus monitor
branch
+M, -M Supply voltage
20–30 V DC
ETb, ERT Storey call button
Terminal assignment SNG 850-...
L1, N Power connection
Ta, Tb In-Home bus
b, c Power supply 12 V AC
Tö, Tö Relay contact door
release
Li, Li Relay contact light
Commissioning
Simple commissioning using
Plug+Play programming.
Upgrade capability
The Basic set can be extended with
the following components. The
overall extension of the Basic sets set
must not exceed 10 users, whereby
one door station supports two users.
• Video indoor station Siedle Basic
VIB 150-...
• Audio indoor station Siedle Basic
AIB 150-...
• DoorCom Analog DCA 650-...
• Bus switching unit BSE 650-...
• Video door station of the In-Home
bus system with BCM 653/658-...
• Audio door station of the In-Home
bus system
• Further system components may
be needed.
Specifications CV 850-...
Colour system: PAL
Image pick-up: CMOS sensor 1/3"
756 x 504 Pixel
Resolution: 550 TV lines
Lens: 3,7 mm
Pick-up angle: horizontal appr. 65°,
vertical appr. 50°
Mechanical adjustment range:
30° horizontal/vertical
Integrated LED lighting
2-step heating:
12 V AC, max. 110 mA
Supply: via In-Home bus
Contact type: contact 24 V, 2 A
Protection system: IP 54, IK 8
Ambient temperature:
–20 °C to +40 °C
Dimensions (mm) W x H x D:
82 x 226 x 35
Specifications VIB 150-...
Operating voltage: via In-Home bus
Operating current: on supply via
+M/–M max. 300 mA
Ambient temperature:
+5 °C to +40 °C
Dimensions (mm) W x H x D:
135 x 115 x 24
