DESCRIPTION OF THE DEVICE
Front
1
5
(1) Mounting bracket
(2) Mounting points for additional fixtures*
(3) Bar with white LEDs
*Attaching further lighting effects
The light set offers mounting points for attaching further lighting effect units (e.g. spot lights, flower effects or lasers). For this loosen the
fixation screw on the upper side, attach the light effect through its bracket and tighten the fixation screw.
Rear
7
(7) IEC outputs for additional fixtures
(8) Display with programming buttons
(9) Microphone
(10) USB port for QuickDMX wireless receiver
(11) DMX input
8
9
10
11
12
3
2
1
4
6
(4) Infrared sensor for the remote control
(5) Fixation screws
(6) Spots with RGBW LEDs
13
14
15
(12) DMX output
(13) Stand sleeve with fixation screw
(14) Fuseholder
(15) Power input
(16) Safety eyelet
25/40
7
16
00132433, Version 1.0
