11.2 Sample computations

Sample calculation 1
Count the horizontal lengths
Flue pipe lengths
Bend
Total
Count the vertical lengths
Flue pipe length A
Roof terminal G
Total
Sample calculation 2
Count the horizontal lengths
Flue pipe lengths J + L = 0,5 + 0,5 1 m
Bends K+ M = 2 + 2 m
Wall terminal
Total horizontal length
Count the vertical lengths
Flue pipe length H
Total
17 < < < <
C+E = 1 + 1 2 m
D = 1 x 2 m 2 m
4 m
1 m
2 m
4 m
1 m
6 m
1 m
1m
1 m
