Parameter "P-19"
Set The Schedule
Important Schedule Warning.
When the thermostat is associated with the
Tydom application, it is recommended to use
the Tydom application to carry out the
programming.
This configuration parameter
is used to set the schedule for
Auto mode.
Select parameter "P-19", "Sc.s"
means "set the schedule".
Parameter
Figure 1
After entering the parameter,
press button and to select
the item to be viewed:
hour, minute, set point
temperature, the corresponding
icon will flash slowly to indicate
Enter Schedule
it can be adjusted.
Setting Figure 2
For instance, the figure "Enter Schedule Setting
Figure 2" shows the heating temperature of the first
period of Monday is 28°C.
If you need to configure an element, after selecting
it, press button to enter the configuration page,
the icon will flash slowly, the figure "Hour Setting
Figure 3" shows the interface of setting the hour and
the figure "Heat Temp Setting Figure 4" shows the
interface of setting the set point temperature.
Press button or to modify the value and,
then press button to save the setting, or press
button to quit setting without saving.
When saving the setting, 4 periods stand for
morning, noon, afternoon, night, if the configuration
parameters are incorrect, the setting will not be
saved and previous setting will be kept, and error
warning will be displayed on the screen.
Hour Setting
Figure 3
Heat Temp Setting
Figure 4
Error Warning
Activate the schedule
In Auto mode, the device will work according to the
temperatures set in the schedule.
When this function is active, one of the 4 icons
will be displayed , these stand for the
4 periods of a day: morning, noon, afternoon, night.
Default time schedule is as follows:
Monday ~ Friday Saturday - Sunday
7:30, 20°C,
7:30, 24°C,
12:00, 15°C,
12:00, 21°C,
18:00, 26°C,
18:00, 28°C,
22:30, 17°C
22:30, 17°C.
Other Displays
If the device is
malfunctioning, an error
code will flash slowly on the
screen, the error codes are
as follows:
E1: Sensor error.
: Room sensor error.
: Floor sensor error.
E2, storage error, action
cannot be stored.
E3 ZigBee internal error.
