Parameter "P-02"
Factory Reset
- Step 1:
If the device has already been
added to a Tydom, use the app
to remove the association.
Go to <settings> > my devices,
select the device > advanced
options > delete.
- Step 2:
Select parameter "P-02", then
press button ,
press button or until
you reach ("Sy.r" means
system reset default),
the icon "rE" ("rE" means reset default) will be shown
at the center of the display, then short press button
to enter factory reset process, and the device will
restart.
The device will be removed from the Zigbee network
and all parameters will be restored to factory default.
Parameter "P-03"
Display Brightness
Select parameter "P-03", "Ll"
means lcd light, available
setting range is Ll.1 ~ Ll.3:
Ll.1: Low 20%,
Ll.2: Mid 50%,
Ll.3: High 100% (factory default)
Parameter "P-04"
Button Buzzer Volume Level
Select parameter "P-04", "bu"
means buzzer, available range
is bu.0 ~ bu.3:
bu.0: disabled (factory default),
bu.1: Low,
bu.2: Mid,
bu.3: High.
Parameter "P-05"
Floor Sensor Type
Select parameter "P-05",
available range is :
12K: NTC 12K/25°C
100K: NTC 100K/25°C
50K: NTC 50K/25°C
15K: NTC 15K/25°C
10K: NTC 10K/25°C
(factory default).
Parameter "P-06"
Sensor Selector (Controller)
This parameter enables the
selection of the sensor that the
device controls in relation to
temperature adjustments.
(Co = Controller).
Select parameter "P-06",
available setting range is:
Co.r: room sensor (factory default),
Co.f: floor sensor
Co.m: MaxGuard (floor and room sensor)
Installation environment.
The choice of sensor is vital to ensuring the
correct operation of your thermostat according
to your installation.
Room sensor:
Temperature adjustment refers to room temperature,
adjustment of heating is determined by the
hysterersis.
Floor sensor:
Temperature adjustment refers to floor temperature,
adjustment of heating is determined by the
hysterersis
MaxGuard:
This setting is used on wooden or parquet floors
to avoid overheating. Heating control refers to
the room temperature sensor, when the floor
temperature is over 27°C, the output will be forced
to turn off, the icon will flash slowly, at an
interval of 1S, until the floor sensor temperature is
under 26.5°C, then the device will return to normal
operation via the room temperature sensor.
Parameter "P-07"
Room Temp Sensor Compensation
Select parameter "P-07",
available setting range is:
-3 to +3, unit is °C,
factory default value is 0,
increments are of 0.5°C.
Parameter "P-08"
Floor Temp Sensor Compensation
Select parameter "P-08" ,
available setting range is:
-3 to +3, unit is °C,
factory default value is 0,
increments are of 0.5°C.
Parameter "P-09"
Frost protection Temperature
To prevent the room from freezing while no one is at
home, this parameter can be used, and it is executed
when the thermostat is off, and the reference sensor
is room sensor.
Select parameter "P-09", available setting range is:
0 (frost protection disabled), 5-10°C, factory default
value is 5°C.
Parameter "P-10"
Unit of Displayed Temperature
This parameter can be used
to set the unit of displayed
temperature.
Select parameter "P-10", "Un"
means unit display, available
setting range is:"F" and "C",
factory default value is C.
Note:
All temperature settings are based on the unit °C.
