To REMoVE/REPlACE shIElD
To remove the shield, first place it in the fully open
position. When the shield is in its fully open position,
levers appear under the shield holding arms. With
your thumb or a rod like a ballpoint pen push these
levers straight forward in the arrowed direction until
they stop (about 5mm, 1/8"), which releases the
locking system. Then, raise the shield further to
remove shield assembly from helmet.
NoTE:
The shield cannot be removed from any other
position as the locking system will be engaged.
To replace shield, place each shield holding arm
onto base plate on each side so that the lower edge
of the arm on each side lines up with the guide line
marked on each base plate.
NoTE:
The shield can only be replaced at its remove/
replace position. Check its angle as you remove
the shield and duplicate it to replace the shield.
