10
English
To replace the shield holding arms, first slip the
upper slot of the shield into the upper bracket of
the shield holding arm <1>, next slip the lower slot
of the shield into the lower bracket of the shield
holding arm <2>, then slide the shield holding arm
downward until it is fully snapped into place <3>.
〈2〉
Be sure the lock lever at the lower bracket returns
to the correct position as illustrated <4>.
〈4〉
WARNING:
if the lock lever at the lower bracket is not in
the correct position the shield may come off
when you try to replace the shield or when you
operate your motorcycle.
To REMoVE/REPlACE ChEEKPADs
When first servicing the cheekpads, it is suggested
that you do only one at a time so that the other can
be used as a reinstallation guide.
To remove the cheekpads, first undo chinstrap. Pull
the pad toward the front of the helmet, then inward
to release and slide it off the strap.
To take off the fabric covering for washing, peel the
covering off over the front edge of the cheekpad
assembly until all the fabric is on the face side
surface. Then draw the rectangular collar through
the opening by rotating the collar vertically and
putting into the opening.
To wash fabric coverings, put them into lukewarm
water with small amount of laundry soap or your
own shampoo and wash gently by hand. Rinse well
with fresh water and wipe off with a soft cloth. Dry
them in the shade at ambient temperature.
WARNING:
Never use petrol, thinner, benzene or any other
solvents.
